Cavity Three-Way Splitter
Three-way splitter is used to deliver the enhanced signal to 3 or more rooms. To cover the entire area, this accessory should be used with 2 additional indoor antennas for a single booster.
- Full band (698-2700 MHz)
- Retransmits signal in 3 directions
- Easy to install
- Meets the international technical standards
Description
Three-way splitter is used to deliver the enhanced signal to 3 or more rooms. To cover the entire area, this accessory should be used with 2 additional indoor antennas for a single booster. The splitter supports 2G, 3G and 4G signals at the frequency range from 698 to 2700 MHz.The accessory is suitable for all HiBoost repeaters.
| Frequency Range | 698-960/1710-2700 MHz |
|---|---|
| Splitter Loss (dB) | 4.8 |
| Insertion Loss (dB) | ≤ 0,4 |
| Input & Output Impedance | 50 ohm |
| Isolation (dB) | No |
| VSWR | ≤ 1.3 |
| Max. power | 50 W |
| Connector Type | N-Female |
| Operating Temperature | -35 ℃~+60℃ |
| Splitter Weight | No |
